M/V BIESBOSCH

We performed detailed engineering for the M/V BIESBOSCH & Steel structure drawings, workshops, nestings prepared by Nazmi BAYAR Design & Consultancy

The vessel designed and constructed as a Single screw, diesel driven Shallow Draft General Cargo Vessel, with one box hold construction with two movable bulkheads, accommodation and machinery space located aft.

The vessel's tanktop produced with HARDOX for higher tanktop Strength, Vessel designed for low air draft (6.30m in ballast condition) so wheelhouse & masts are foldable

    TECHNICAL SPECIFICATIONS

  • Name of Vessel: BIESBOSCH
  • Owner: DG COASTER B.V.
  • Type of Vessel: General Cargo Vessel
  • Flag: Dutch
  • Classification Society: Bureau Veritas
  • Hull Material: Steel Gr.A & AH36 (Tantop=Hardox)
  • Max Speed: 12.0
  • Accommodation: 6 person

    • MAIN DIMENSIONS

  • LOA: 87.75m
  • LBP: 84.71m
  • Moulded Breadth: 13.20m
  • Maximum Breadth: 13.25m
  • Depth: 5.70m
  • Draught: 4.15m
  • Deadweight: 2980
  • Gross Tonnage: 2256

    • MAIN PROPULSION

  • Main Engine: ABC 6MDZC
  • Power: 1x1200kW@1000rpm
  • Propeller: 1XSolid Screw Propeller with Nozzle
  • Generators: 2x213kVA+1x87kVA

    • CAPACITIES

  • Cargo: 4350m3
  • Ballast: 1530m3
  • HFO: n.a.
  • MDO: 150m3
  • FW: 32m3
